Keyboard : 76 keys (Piano-style)
Touch Response : 2 sensitivity levels, Off
Sound Source : AHL (Tri-element)
Maximum Polyphony : 64
Tones : 820 built-in tones including 50 drawbar organ tones (100 user tones)
Layer/Split : Layer, Split(variable split point)Reverb: 10 types
Chorus: 5 types (simultaneous use with DSP not supported.)
DSP: 100 preset, 100 user (simultaneous use with Chorus not supported.)
EQ(Equalizer): 5(Off, Soft, Bright, B.Boost, Powerful)
Auto Harmonize: 12
Arpeggiator: 150260 built-in rhythms (100 user rhythms)
Modes: CASIO Chord, Fingered 1, Fingered 2 (6th off), Fingered 3 (on bass), Full Range Chord
Controllers: Start/Stop, Intro, Normal/Fill-in, Variation/Fill-in, Synchro/Ending
Built-in Songs : 5 (demo tunes)
Metronome Beats: 0, 2, 3, 4, 5, 6 (Tempo range: quarter note = 30 to 255)
Song sequencer: 16 multi tracks + 1 System Track, 5 songs, approximately 30,000 total notes (real-time recording, step recording, song edit, track edit,event edit, punch-in/out)
Audio recording/playback: 5 files maximum (Approximately 13 minutes of recording per file)
Mixer: 32 channels + EXT IN (INST IN, MIC IN), 9-slider operation
Pattern sequencer: real-time recording, step recording, quantize, Easy Edit, Event Editor, part parameters (100 user rhythms)
Drawbar organ: 9 drawbars/50 built-in tones/50 user tones
Tone editor (100 user tones)
Registrations: 96 setups (6 sets x 16 banks)
Music preset: 305 preset with chord progression, chord edit (100 user presets)
One-touch preset: 260 presets
Temperaments (scales): Preset scale (Equal temperament + 16 types)/scale fine tune
Octave shift: ±2 octaves
Rhythm/song controller
Pitch bend wheel : 0 to 24 semitones
Modulation button
Sliders (9 sliders used for drawbar organ and mixer)
Large Dial
Key Transpose : ±1 octave (-12 to +12 semitones)
Tuning Control : A4 = 415.5 – 440.0 – 465.9 Hz
Pedals : Standard jack (sustain, soft, sostenuto, start/stop)
Display Screen : LCD with backlight
Supported memory cards: From 2GB up to 32GB SD memory cards or SDHC memory cards
Functions: SMF playback (up to 320KB per file), file save/load/delete, card format
Save/load: Registrations, user rhythms, user tones, user drawbar organ tones, user DSPs, user music presets, song sequencer songs, audio recording files
GM Compatibility: Level1
Terminals: USB
Speakers : 12cm x 2 + 3cm x 2, bass-reflex system, speaker on/off
Amp Output : 7W＋7W
Input/Output Terminals : Mic in/ Inst in/ Audio in/ Line output (L/MONO, R)
Headphones (standard stereo jack)
Sustain/assignable
USB: type B
External power (12V DC)
Batteries: D-size x 6/ AC adaptor: AD-A12150LW
Dimensions (W x D x H) : 1,161 x 385 x 147 mm
