Keyboard : 61 standard size keys
Touch Response: Sensitivity 3 types, Off
Maximum Polyphony : 64 notes (32 for certain tones)
Preset Tones: 800 (43 Indian)
User Tones: 100
Other: Layer, split (configurable split point, lower point, chord point settings)
Reverb: 32 types, Off
Chorus: 16 types, Tones
Delay: 20 types, Tones
DSP: 100 types (Can be applied to user tones using DSP editing.), DSP tones
Master Effects : Equalizer (10 presets)/ 4-band User Equalizer
External Input Effects : Center cancel (vocal cut) for input from the Audio In jack
Beat: 0 (accented tone off), 1 to 16
Tempo: Tempo value: 20 to 255
Demo Songs : 3
Built-in Songs: 30
User-recorded Songs: 10
USB Memory Songs: Playback of standard MIDI files (SMF format 0/1), CASIO MIDI files (CMF format) on a USB flash drive is supported.
Playback of audio files on a USB flash drive is supported.
Supported File Formats: WAV format, 44.1 kHz 16 bit
Other Functions: Center Cancel (Vocal Cut)
Built-in Rhythms: 250 (39 Indian)
User Rhythms: 100
One Touch Presets: 250
Music Presets : 310 (With chord progressions)
Number of Pads: 4
User Phrases: 100 (4 phrases x 25 pads)
Editing Mode: Copy, delete, phrase editing
Affected Parts: Sound source parts, microphone input part
Parameters: Part on/off, volume, pan, reverb send, chorus send, delay send
Registration : Maximum 128 setups (8 setups x 16 banks), registration sequence
Preset tone editing, DSP editing
Memory for storage of edited tones (up to 100)
New rhythm creation, rhythm editing
Memory for storage of created/edited rhythms (up to 50)
Real-time recording, playback
Keyboard Performance Recording: 10 songs, 17 tracks (1 system track, 16 solo tracks)
Memory Capacity: Approximately 40,000 notes (per song)
Editing Mode: Song editing, track editing, event editing, step input
Other Functions: Overdubbing, punch-in recording
Pedals : Sustain, sostenuto, soft, rhythm/song, expression
Controllers : Pitch bend wheel, TOUCH On/OFF button, PORTAMENTO button, MODULATION/ASSIGNABLE button
Transpose: ±1 octaves (-12 to 0 to +12 semitones)
Octave Shift: Upper 1/Upper 2/Lower 1/Lower 2, ±3 octaves
Tuning: A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
Part coarse tune: For each keyboard part, ±2 octaves (-24 to 0 to +24 semitones)
Part fine tune: For each keyboard part, ±99 cents
Scales: 17 preset scales, scale fine tuning
Auto Harmonize: 12 types
Arpeggiator: 150 types
SFX: 57
MIDI : 16ch multi-timbre received, GM Level 1 standard
USB Flash Drive Port: Type A
USB Port: Type B
Pedal 1 Jack: Standard jack
Pedal 2, Expression Jack: Standard jack
Headphones Jack: Stereo standard jack
Audio Input Jack: Stereo mini jack/Input impedance 9 kΩ, Input sensitivity 200 mV
Microphone Input Jack: Standard jack (Connect a dynamic microphone.)/ Input impedance 3 kΩ, Input sensitivity 10 mV
AC adaptor only
AC Adaptor: AD-E24250LW
Auto Power Off: Approximately 30 minutes after last operation; Can be disabled.
Speakers : 10cm x 2 (Output: 15W + 15W)
Power Consumption : 15 W
Dimensions (W x D X H) : 94.8 x 38.4 x 11.6 cm
